Dinkle DIN Rail Block Kit DK10N Red/Black with Jumpers Ground Terminal Blocks, 6-20 AWG, 60 Amp, 600 Volt
5.0 (60 items)
Limited Time SaleUS$23.39 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211033380 | Release Date | 2026/04/04 | List Price | US$15.60 | Model Number | 211033380 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This kit includes 4 DK10N-BK Dinkle terminal blocks, 4 DK10N-RD Dinkle terminal blocks, 2 DK10N-PE ground blocks, 2 SS4 end brackets, and 1 DK10NC-BK end cover, 4 DSS10N-02P jumpers, and a 7" piece of aluminum RoHS rail. These are 8 separate circuits, but you can use the jumpers to make them in common. Fully customizable! Technical Data (UL) Rated Voltage: 600V Rate Current: 60A Conductor Cross-section, Solid (AWG): 20-6 Conductor Cross-section, Flexible (AWG): 20-6 Rated Impulse Withstand Voltage: 8KV Torque (N-m): 1.3 Screw: M4 Wire Strip Length: 12-14mm Insulating Material: PA TxHxW (mm): 10 x 49.3 x 42.9 (Individual Blocks) DIN Rail (mm): 35, 32 Jumper/Bridge: Press-fit/Insertion. Accepts TM49W marking tags.
- Kit for Solar Combiner or Power Distribution
- UL 600V Rating
- UL 6-20 AWG Rating
- UL 60A Rating
- All separate terminals made common with jumpers
| UPC | 680847733509 |
|---|---|
| Gauge | 6.0 |
| Model | DK10NC-BK |
| Pitch | 49.3 Millimeters |
| Voltage | 600 Volts |
| Brand Name | International Connector |
| Part Number | Kit DK10N Red/Black |
| Manufacturer | Dinkle |
| Material Type | PA66 Insulating Material |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 60 Amps |
| Number Of Poles | 8 |
| Centerline Length | 49.3 Millimeters |
| Specification Met | UL |
| Number Of Contacts | 20 |
| Included Components | Terminal Blocks and Accessories |
| Number of Positions | 8 |
| Item Dimensions W x H | 1.69"W x 1.94"H |
